直柱标准型自由指定型D尺寸m6
· 请按照选型步骤①-④选择型式和参数后进行订购。
订货举例：型式（①Type.②D)-③P-④L
BACFPKR5-P2-L5
|
Type |
材质 |
表面处理 |
硬度 |
|
|
D尺寸P6 |
D尺寸m6 |
|||
|
BACFPKR |
BACFMKR |
SKS3 |
/ |
58~61HRC |
|
BACFPKRN |
BACFMKRN |
SKS3 |
无电解镀镍 |
58~61HRC |
|
BACFPCR |
BACFMCR |
SUS440C |
/ |
50~55HRC |
|
BACFPS |
BACFMS |
SUS303 |
/ |
/ |
·
|
型式 |
D容差 |
P |
L |
壁厚（E） |
R |
||
|
Type |
D |
D公差（p6） |
D公差（m6） |
||||
|
|
5 |
+0.02 |
+0.012 |
2.00~2.50 |
5.0~6.0 |
1.25~1.50 |
0.8 |
|
|
7 |
+0.024 |
+0.015 |
2.00~3.50 |
5.0~8.0 |
1.75~2.50 |
|
|
BACFPKR |
8 |
3.00~4.50 |
5.0~13.0 |
1 |
|||
|
BACFPKRN |
10 |
4.00~6.50 |
5.0~20.0 |
1.75~3.00 |
|||
|
BACFPCR |
12 |
+0.029 |
+0.018 |
6.00~8.50 |
2.0 |
||
|
BACFPS |
15 |
8.00～10.50 |
5.0~40.0 |
2.25~3.50 |
|||
|
BACFMKR |
18 |
10.00～12.50 |
2.75~4.00 |
||||
|
BACFMKRN |
20 |
+0.035 |
+0.021 |
12.00～13.50 |
3.25~4.00 |
||
|
BACFMCR |
22 |
4.25~5.00 |
|||||
|
BACFMS |
25 |
13.00～15.50 |
4.75~6.00 |
||||
|
|
26 |
15.00～16.50 |
4.75~5.50 |
||||
|
|
30 |
16.00～20.50 |
5.0~60.0 |
4.75~7.00 |
3 |
||
|
|
35 |
+0.042 |
+0.025 |
20.00～25.00 |
5.00~7.50 |
||
·
！P≤3.59时，L≤PX2.5 P≥3.6时，L≤Px3.0 !(D-P)/2≤2时，R为2以下。
